Powervac SVTS-550R: Rotary Type Semi-Automatic MAP Cup and Tray Sealing Machine
Introducing Powervac’s Rotary Type Semi-Automatic MAP Cup and Tray Sealing Machine SVTS-550R, a high-performance solution designed for efficient packaging across a diverse range of products. This versatile machine is tailored for packaging Gulabjamun, Rasgulla, Lassi, Rabdi, juice, assorted sweets, dry-fruits, cakes, ready-to-eat foods, frozen foods, vegetables, cut-fruits, and more, making it ideal for medium-scale production of up to 2500kgs per day.
Rotary Design for Time Efficiency
The SVTS-550R features a rotary design that significantly reduces loading and unloading times, ensuring a streamlined production process.
Accurate Gas Flushing Systems
Benefit from precise gas flushing systems that enhance the shelf life of your products by maintaining optimal gas levels within the sealed trays.
Easy Mould Changing Systems
Experience seamless transitions between different packaging requirements with the machine’s user-friendly and efficient mould changing systems.
Low Air & Gas Pressure Alarm
The built-in alarm system alerts operators in case of low air or gas pressure, preventing potential disruptions and ensuring the machine’s continuous operation.
Mobile with 4 Nos. Trolley Wheels
Enhance the flexibility of your production setup with the machine’s mobility feature, equipped with four trolley wheels. Two of these wheels are lockable, providing stability during operation.
Easy Mould Changing & Stainless Steel Body
The machine boasts a stainless steel body, ensuring durability and hygiene. Combined with easy mould changing features, it offers a convenient and efficient packaging solution.
Sensor-Based Vacuum & Gas Flushing
Benefit from advanced sensor-based technology that automates the vacuum and gas flushing processes, optimizing the packaging quality and reducing the need for manual intervention.
Powervac’s SVTS-550R Rotary Type Semi-Automatic MAP Tray Sealing Machine is engineered to meet the demands of modern packaging with precision, efficiency, and ease of use. Elevate your production capabilities and deliver superior packaging for a wide array of food products.
Standard Features
- Semi Auto But Shuttle Type Map Tray Selling Machine To Save Time For Trays LoadingUn-loading, Suitable Pre-made Trays And Cups.
- Product Can Be Pack Like Sweets, Dry-fruits, Cakes, Ready Eat Foods, Frozen Food, Etc.
- Accurate Vacuum-gas Flushing Systems.
- Easy Mould Changing & Stainless Steel Body, No Sharps Edges, Use Cast Aluminum & Other Nonferrous Materials To Safe Rust Issue And Easy Cleaning.
Technical Specification
| MACHINE MODEL | SVTS-550R |
| Machine Dimension(LXWXH) | 1000x1155x1415 |
| No.of Trays Can Feed At a Time | 1 to 4-depend upon tray/Cup size |
| Down Chamber Height | 75mm/ Can Be Customized As Per Requirment |
| Max Diameter Of Film Roll | 220 mm Diameter |
| Control Panel | POWERVAC Touch Screen HMI PLC |
| Electric Supply | 4 KW |
| Vacuum Pump | 40 M/h(BUSCH) |
| Cycle Per Minute [with Map/only Seal] | 4/7 |
| Operation On Trays | Vacuum+ Gas+ Sealing Cutting & Only Sealing-cutting |
| Machine Construction | Stainless Steel And Anodised Aluminium |
| Machine Weight | 350KG |
| Voltage | 440V-3PH/50Hz |
Optional Features
- Eye Mark Sensor For Printed Roll.
- Can Be Customized According To Application.
- Buffer Gas Tank.
