Standard Features
- Horizontal dual chamber type model to save loading- unloading time.
- Mobile with 4 nos. trolley wheels. wheels will be lockable.
- Design suitable for high productivity up to 10kg pack with high speed vacuum pump.
- Heavy duty one piece cast aluminum top.
- Mitsubishi (Japan) PLC based control panel with 4-line LCD display.
- German make vacuum pump
- Adjustable vacuum time sealing time, etc. long lasting heating elements for accurate sealing result. stainless steel body, no sharp edges, use cast aluminum &other nonferrous materials, to safe rust issue and easy cleaning.
Optional Features
- Insert gas flushing unit.
- Vacuum & gas control by sensor for accurate level.
- BUSCH (Germany) Vacuum Pump
- Mould and Formers as per require pack size.
Technical Specification
| MACHINE MODEL | ADCH-860 |
| Usable Chamber Width (Distance Between Seal bars)(W1/W2) |
W1 – 720 W2 – 322 |
| Usable Chamber Height (H) | 195 |
| Seal bar Length (L) | 860 |
| Number of Seal Bars | 2/4 |
| Seal Width | 6/8 |
| Machine Dimension (LxWxH) | 2058 X 925 X 1070 |
| Machine Weight | 550 Kg |
| Voltage | 440V – 3PH – 50Hz |
| Electric Power Supply | 5 KW |
| Cycle Time | 20 – 25 Seconds |
