Standard Features
- Specially design for high productivity.
- Suitable for premado trays and cups.
- Product can be pack like sweets, dryfruits, cakes, ready to eat foods, frozen foods, vegetables and fruits.
- Mobile with 4 nos, trolley wheels. 2 wheels will be lockable for steadiness.
- Buffer Gas Tank.
- Accurate vacuum and gas flushing systems.
- Easy Mould changing systems.
- Stainless steel body, no sharp edges, use cast aluminum & other nonferrous materials to safe rust issue and easy cleaning.
- High speed vacuum pump (Busch Germany).
Optional Features
- Tray denester system.
- Eyo mark sensor for printed roll.
- Liquid dosing unit, auto weighed granules materials
- Check wolghers and metal detector can be integrated.
- Can be Customize according to application.
Technical Specification
| MACHINE MODEL | AVTS-500 | AVTS-550 | AVTS-600 |
| Machine Dimension LxWxH | 1000x1155x1415 | ||
| No.of Trays Can Feed At a Time | 3 | 4 | 5 |
| Tray Loading Area | 700 mm | ||
| Bottom Chamber Height | 45 mm Can Be Customized | ||
| Control Panel | Touch Screen HMI- Mitsubishi(japan) | ||
| Electric Supply | 7 KW | ||
| Vacuum Pump | BUSCH(Germany) | ||
| Vacuum And Gas Sensor | SMC (Japan) | ||
| Cycle Per Minute [with Map/only Seal] | 6/10 | ||
| Operation On Trays | Vacuum Gas + Gas+ Sealing & Cutting | ||
| Machine Construction | Stainless Steel | ||
| Machine Weight | 500 Kg | ||
| Voltage | 440V-3PH/50Hz |
